Rotogravure Printing Sleeve
Elastomer coatings & covers for gravure printing gayatri rubtech offers special elastomer coatings and covers for rubber impression rollers, suitable for gravure printing with inks based on acetate solvents, alcohol, mek, and up to 20% toluene.
materials available include epdm, nbr. the fiberglass conductive sleeve with special compounds ensures antistatic properties, while pressers with electrostatic printing assistance(esa) provide enhanced printing quality.recommended cleaning with 100% ethyl acetate.
Types Of Roller Sleeves
- standard pressers (without esa)
- pressers with electrostatic printing (esa) 1-layer/2-layer/3-layer
Benefits
- high resistance against pressure and mechanical load
- high resistance against solvents (alcohol, ester, toluene)
- choice of adequate mixture according to esa demands
- possibility of recovering rollers and sleeves
Sleeve Types By Shapes
- conical sleeve system
- cylindrical
- hardness 70-75
- EPDM, Hylone, NBR
- With ESA / Without ESA
- Special rubber coating for rotogravure printing machine
- Maximum Load: 20 to 22 KG
- Maximum Temp: 100 to 120 Degree
- With antistatic compound
- Conductive
